USR-DR302 to przemysłowy media konwerter z RS485 na LAN w obudowie do montażu na szynie DIN. Urządzenie zapewnia przeźroczystą transmisję danych. Obsługuje protokół Modbus RTU oraz TCP IP.

Najważniejsze cechy:

USR-DR302
Work Voltage	DC 5.0～36.0 V
Work Current	130mA@5V
Ethernet Port	RJ45,10/100Mbps
Serial Port Baud rate	600-460.8K（bps）
Serial Port	1x RS485
Network Protocol	TCP/IP, UDP, ARP,ICMP,IPV4
IP Type	Static IP,DHCP
DNS	Support
Configuration	Software, Web-page, AT command
Work Mode	TCP Server/TCP Client/ UDP Server/UDP Client Modbus RTU to TCP
Similar RFC2217	Support
httpsd Client	Support
TCP Server Connection	Support to connect max 8 TCP client
Network Caching	Send: 6Kbyte, Receive:4Kbyte
Serial Port Caching	Receive: 2Kbyte
Average Transmission Delay	<10ms
Software	VCOM, USRIOT_Cloud, Setup software, test proforma
Packaging Mechanism	4 bytes package time 1024 bytes package length
Certificate	CE, RoHs, FCC
Grade	IP30, 1.5KV
Size	71 x 60 x 25 mm
Work Temp	-40～85c
Storage Temp	-40～105c
Work Humidity	5%～95% RH
Storage Temp	5%～95% RH
